Solaris Capnograph

Solaris – Hand held capnography.  Compact, reliable and high performance, offering mainstream or sidestream EtCO2 measurement

• Durable, compact, lightweight
• Capnograph with trends; SpO2 with waveforms.
• Data storage for up to 100 patients; 72 hours per patient.
• Suitable for Adult, paediatric and neonate.
• Specially designed protective boots for rugged use.

Product: Solaris Capnograph

Part No: NT1D-E-LC

Specifications:

• Bright, Easy-to-Read Large LED Display
• Durable, Compact, and Lightweight
• Audible/Visual Alarms with Adjustable Alarm Limits
• Can be used toSpot-Check or Continuous Monitoring
• Suitable for Adult and pediatric Patients
• SpO2 Measurement range: 0-100%
• SpO2 Accuracy: +2% during 70%-100%; 0% – 69% unspecified
• Pulse Rate Measurement range: 30 bpm – 250 bpm
• Pulse Rate Accuracy: 1 bpm +/- 2% (whichever is greater)
• EtCO2 Measurement range: 0-150mmHg
• EtCO2 Resolution: 0.1 mmHg (0-69)mmHg; 0.25mmHg (70-150)mmHg;
• EtCO2 Accuracy: +/- 2mmHg (0-40)mmHg; +/- 5% (41-70)mmHg;+/- 8% (71-100)mmHg; +/- 10% (101-150)mmHg
• Respiration Rate Measurement range: 0-150 bpm
• Respiration Rate Accuracy: +/- 1bpm
• Three levels of visual, audio alarms
• Operating Temperature: 0°C – 50°C
• Humidity: ≤95%
• Altitude: -390m – 5,000m
• Transport/Storage temperature: -20°C – 70°C
• Dimensions: 73mm W x 127mm H x 23mm D
• Maximum weight: 500g
• Battery type: Lithium Polymer Battery Pack
• Internal power supply: 3.7 – 4.2V/4400mhA
• II type power adapter: Input AC100-240V 50/60Hz, Output DC 5V
• Battery Capacity: ≥ 12 hours (SpO2 only)
• Battery Capacity: ≥ 5 hours (SpO2 + CO2)

• Adult Finger Sensor (hard)
• Paediatric Finger Sensor (hard)
• Adult Finger Sensor (Soft)
• Paediatric Finger Sensor (Soft)
• Mainstream CO2 Sensor
• Sidestream CO2 Sensor
• Protective Boot
